Extruders

                    Extruder                                                           Portable Extruder                                             Foam Extruder
Extruders designed with 25-150 mm barrel diameters, 20:1 to 40:1 L/D, double reduction helical gear reducer with heavy duty thrust bearing, monolithic barrels with cutaway feed section and water cooling jacket, bolt on or C-clamp front flanges with optional by-pass valves, cast aluminum or bronze barrel heaters, air or liquid cooling of the barrel, AC motors with vector drives, stainless steel hoppers with full pellet handling systems, custom designed feed screws, high temperature/corrosion resistant versions available.


General Purpose Applications-
  Primary Insulation, Jacketing      		Specialty Applications-
 Foam Insulation based on
Fine's Proprietary Physical Foam Technology

Extruder for PE or PVC
Extruder for FEP
Screw diameter
25 mm to 150 mm
25 mm to 65 mm
Extruders L/D range
20 to 30
25 to 30
Motor power
up to 200 kw
up to 50 kw

Extruder for PE foam
Extruder for FEP foam
Screw diameter
40mm to 150mm
40 mm to 65 mm
Extruders L/D range
34 to 40
32 to 36
Motor power
up to 200 kw
up to 50 kw

We also offer custom designs to meet you specifications!
